Agrional Pneumatic Precision Seeders allow you to plant seeds such as beet, corn, sunflower, cotton, soybean, peanut, pumpkin, watermelon, melon, cucumber, and onion at the desired spacing between rows. They are connected to the tractor using a three-point hitch system. The machines can be produced in configurations ranging from 2 to 12 rows as desired. The row spacing can be adjusted to various widths, including 45, 70, 90, and 140 cm. The minimum row spacing is 27 cm and can be precisely adjusted using the measurement values on the chassis profile. By loosening the connection bolts of the planting unit, the row spacing can be easily changed. All connections on the chassis profile are movable, which facilitates the adjustment processes. Seeding Mechanism and Precision Each seeding unit independently operates the movement of the seed discs via a 12 V brushed DC servo motor[max 1.2 Amper].


ModelNumber of UnitsTotal Length (Chassis)WidthHeightDistance Between RowsSeed Hopper VolumeFertilizer Hopper VolumeP.T.O. RpmTractor PowerWeight (With Fertilizer System)
QuantitymmmmmmcmDm³Dm³RpmMin HPKg
SmartPlant-442800-32002300160045-70-75-9535 x 4160 x 2540601060
SmartPlant-5532002300160045-70-7535 x 5160 x 2540701240
SmartPlant-6640002300160045-70-7535 x 6200 x 2540801420
SmartPlant-8856002300160045-70-7535 x 8200 x 45401001950
